Sinotruk howo 8 tons road sweeper Vehicle technical parameters
Volume of clean water tank (m3): 3.5m3 Volume of garbage tank (m3): 8.2m3
Box material: stainless steel
Dimensions (mm): 7940x2500x3150
Cleaning width (m): 3.5m
Cleaning speed (km/h): 3-20km/h
Large cleaning capacity: 70000m3/h
Secondary engine: Cummins 140 hp
Sinotruk howo 8 tons road sweeper Chassis technical parameters
Chassis name: Sinotruk Steyr
Chassis model: ZZ1161H501GE1
Number of axes: 2
Wheelbase (mm):4700
Cab type: flat head row and half
Number of passengers allowed: 2
Engine horsepower: Sinotruk 180 horsepower
Gearbox model: 6-speed gearbox
Tire specification: 9.00R20 steel tire
Front and rear axles: 4/10 tons
Fuel Type: Diesel
Environmental Standard: National V
ABS anti-lock braking system
Standard: braking system, air brake, heating and cooling, steering assist
Sinotruk howo 8 tons road sweeper upper body basic configuration
The standard configuration
With 4 sweeping discs, Cummins auxiliary engine; vigorous motor; Schneider control switch; Taiwan solenoid valve group; maintenance-free self-separating clutch; maintenance-free fan; stainless steel water tank; The rotating mechanism of the brush arm uses high-tech wear-resistant engineering spacers, without butter; precision cold-formed seamless hydraulic oil pipes.
Optional configuration: users can choose to install front flushing, rear spraying, spraying, self-cleaning reel, operation monitoring system, auxiliary suction pipe device, snow shovel and other configurations according to personal needs
1. The 8-ton road sweeper of Sinotruk howo adopts the special chassis of Sinotruk Steyer series sanitation vehicles, with solid workmanship and strong bearing capacity.
2. The powertrain of Sinotruk howo 's 8-ton road sweeper adopts Sinotruk's 180-horsepower diesel engine, which meets the authentic National V emission standards. In terms of gearbox, it is equipped with a 6-speed manual gearbox, which has fast acceleration and strong power!
3. The 8-ton road sweeper of Sinotruk howo adopts a 10-ton reinforced rear axle, which has a stronger bearing capacity.
4. The 8-ton road sweeper of Sinotruk adopts the Cummins series auxiliary engine of Sino-US joint venture, and the high power can reach 140 horsepower.
5. The 8-ton road sweeper of Sinotruk howo adopts the high-power maintenance-free centrifugal fan of NorthGlass Taixin, a listed company in Luoyang, with large air volume, low noise and stable quality during operation!
6. The 8-ton road sweeper of Sinotruk howo adopts the auxiliary engine to drive the fan. There is a vehicle clutch between the auxiliary engine and the fan. When the fan starts and stops working, it can effectively avoid the impact on the auxiliary engine and protect the auxiliary engine from being damaged.
7. Sinotruk howo 's 8-ton road sweeper adopts stainless steel water tank garbage box, the volume of the clean water tank is 3.5 cubic meters, and the built-in low water level alarm can effectively protect the water pump from being damaged. Greatly prolongs the service life of the box.
8. The 8-ton road sweeper of Sinotruk howo adopts imported high-quality solenoid valve group, which does not stick to the valve to ensure the stability and smoothness of the hydraulic system when the vehicle is working.
9. The 8-ton road sweeper of Sinotruk howo adopts high-quality domestic hydraulic motor, with stable speed and improved cleaning efficiency.
10. The 8-ton road sweeper of Sinotruk adopts a full floating nozzle that can be automatically leveled according to the road conditions, with good cleaning effect and long service life.
11. The 8-ton road sweeper of Sinotruk howo can also intelligently realize the speed regulation of the high, medium and low gears of the sweeper according to different industrial departments, without adding the auxiliary engine accelerator, which can ensure that it can be operated under various pollution conditions. Good results while saving fuel consumption and bristle wear.
12. The 8-ton road sweeper of Sinotruk adopts an ultra-wide 3-hook hydraulic tailgate, and the opening angle of the garbage bin is greater than 85 degrees, which is more convenient for garbage dumping.
13. In addition to the configuration mentioned above, users can also choose to install front, rear sprinkler, spray, self-cleaning reel, auxiliary vacuum pipe, snow shovel and other configurations according to their actual needs.
