Basic configuration of tank body for Sinotruk howo 6X4 water bowser 20000l:
Standard configuration: The tank body of the heavy-duty truck 6X4 22 ton sprinkler truck is made of high-quality steel plate with a thickness of 5 millimeters. The water pressure head is automatically welded, and there are 2-5 anti wave and impact plates inside. It is equipped with a high-power sprinkler pump with a flow rate of 30-60 tons per hour. The pressure is high and the flow rate is strong. It is equipped with a resin transparent liquid level gauge, and the pipeline is connected with seamless galvanized plate. The valve is made of aluminum alloy and stainless steel materials, with 2 layers of anti rust primer and 2 layers of topcoat. The topcoat is baked paint process, and the entire vehicle adopts an assembly line production mode and modular
Specialized functions; The range of the front and right nozzles is 15 meters wide, and the rear fan-shaped cooling and dust reduction valve cover is 15 square meters. There are two high-level showerheads at the top of the tank tail that can be used to irrigate the road green belt. The rear operating platform is equipped with a sprinkler gun with a range of 28 meters, which can be used for long-distance watering and firefighting. Two round nozzle nozzles, two front duckbill nozzles, two shower nozzles, one adjustable water cannon, two self suction hoses, and two toolbox locks are included in the vehicle accessories
Sprinkler anti-aircraft gun, work platform, power take-off, forward flushing, backward spraying, universal nozzle, self flow valve, filter screen, distribution valve, nozzle, with self suction and self discharge function
Optional configuration: Advanced facilities such as spraying tray, medicine pump, anti-corrosion and rust prevention inside the tank, multi-directional inlet and outlet water joints, electromagnetic valve, pneumatic valve, etc. can be added according to customer requirements
Advantages of Sinotruk howo 6X4 water bowser 20000l::
1. Advantages of the vehicle model: Among the sprinkler vehicle models, it has the highest industry share
2 engine advantages: Paired with the high-power Weichai 400 horsepower, Euro 2/3 emission standard, the engine has strong power, faster acceleration, and is economical and fuel-efficient
Advantages of 3-speed variable gearbox: Adopting a heavy-duty truck 10 speed gearbox, with high torque, fast climbing, international quality, and lightweight operation
Advantages of 4-axle: The vehicle is equipped with a high-strength rear axle, which has strong load-bearing capacity and is free of disassembly and maintenance
5 advantages of tank body: The tank body is made of high-quality carbon steel, and the tank body is painted and sandblasted, which is wear-resistant and corrosion-resistant, and has a long service life
