The new cab of Dongfeng Jincheng Yuchai has 350 horsepower per vehicle with a secondary engine, a Fast transmission, a wheelbase of 1850+4400+1350, and 11.00 steel tires.
Cleaning and suction tank configuration: The tank has a volume of about 28 cubic meters, made of 8m carbon steel plate, a clean water tank of about 5 cubic meters, and the remaining suction tanks have a volume of 23 cubic meters. The two compartments are interconnected by ball valves. The middle of the two compartments is equipped with a head, a 350 flow high-pressure cleaning pump, and a 100 meter high-pressure pipe. Optional installation of Shandong 258 water ring pump with 420 horsepower secondary engine. After the reel is installed, the head rotates 180 degrees and the hydraulic pressure of the rear head opens. There is a 600 cement cover on the rear head that can be hydraulically opened to release dirt. There is a 6-inch drain valve on the side, a 6-inch outlet on the rear head, and a 100 inch inlet that goes straight to the top of the tank. The tank is covered with stainless steel plates, a reinforced frame, a dump truck design, and an arrow light at the rear of the tank with a dirt viewing window. Equipped with an 8-meter suction pipe.
Dongfeng 28 cubic cleaning and suction vehicle function introduction: The cleaning and suction vehicle is a multifunctional sewage cleaning vehicle. It is a specialized drainage pipeline dredging operation vehicle that is equipped with a high-pressure flushing system and suction system on the basis of a standard Class II chassis, and is composed of mechanical, hydraulic, and electrical parts. This car has all the functions of a suction car, including suction and fecal functions, and high-pressure cleaning function. It is a fully functional specialized equipment for clearing sewage pipes by flushing out blocked pipes through high-pressure cleaning (usually 60 meters) and then using suction function to remove dirt, achieving the function of joint dredging.
Some people say that cleaning and suction trucks are the same, but here we need to correct it. The two are different. Cleaning and suction trucks have the function of suction trucks and also have cleaning functions, while suction trucks can only play a role in suction. However, the appearance of cleaning and suction trucks is somewhat similar to that of suction trucks. Generally, large cleaning and suction trucks use tank structures, while small cleaning and suction trucks often use water tank side hanging structures, There are relatively few large cleaning and suction trucks. Today, we will introduce a large cleaning and suction truck, which is the Dongfeng 8X4 28 cubic meter cleaning and suction truck.
Because it is a large cleaning and suction truck, it is equipped with a large auxiliary engine and a high-power water circulation pump, which can easily remove some high concentration mud. For relatively dry mud, the high-pressure flushing function can be used to dilute the mud first, greatly improving the suction efficiency
