dongfeng with cummins engine 180hp china truck mounted hydraulic cranes flatbed 10ton hydraulic telescopic boom sale

Dongfeng Tianjin 8-ton, 10 ton truck mounted crane price - Dongfeng Tianjin truck mounted crane manufacturer

Chassis configuration: Dongfeng Tianjin XCMG 8-ton, 10 ton on-board crane adopts chassis, Cummins 190 horsepower or 210 horsepower engine, Shaan Gear 8-speed gearbox, front axle 4.5 tons, rear axle 9 tons, 9.00 steel wire tires for the entire vehicle, cargo box length can reach 5.75 meters, 6.1 meters, cargo box form can be manual or hydraulic telescopic, cargo box bottom plate is 5mm thick, with original air conditioning, directional assistance, original power take-off, ABS anti lock braking system, and air brake system.

Crane configuration:

 Dongfeng Tianjin 8-ton truck mounted crane can be equipped with XCMG 5-ton, 6.3-ton, 8-ton cranes. Crane brands include Guhe, XCMG, Shimei, Zoomlion, etc., with 360 degree full rotation, standard front hydraulic support legs, single or double chamber hydraulic rear support legs, and high-altitude seats.

Dongfeng 6.3 ton truck mounted crane with four straight arms, with a non extended arm length of 4.14 meters, a fully extended arm length of 11 meters, and a lifting height of 12.8 meters. The horizontal lifting parameters are: a lifting arm length of 11 meters for lifting 0.6 tons, a lifting arm length of 7.19 meters for lifting 1.6 tons, and a lifting arm length of 2.5 meters for lifting 6.3 tons.

The Dongfeng 8-ton truck mounted crane has a four section arm length of 4.48 meters without extension, a fully extended arm length of 11.5 meters, and a lifting height of 13.5 meters. The horizontal lifting parameters are: the arm length is 11.5 meters, lifting 1.1 tons, lifting 2.5 tons at 7 meters, and lifting 8 tons at 2.5 meters

 Product advantages:

 1. The Dongfeng Tianjin 8-ton on-board crane adopts the Dongfeng single axle series products, and the cab is developed and designed by a Sino Japanese joint venture. Its main feature is the comfort of driving and riding. Equipped with a Cummins engine, it has low noise and low failure rate, making it more suitable for long-distance transportation;

2. The Dongfeng Tianjin 8-ton truck mounted crane adopts a four section hexagonal lifting arm, which is made of high-strength manganese steel. The lifting arm has strong load-bearing capacity and uses multiple strands of steel wire rope, with strong toughness. It increases the load-bearing lifting torque, prevents slipping during lifting, and improves the safety factor of the operation;

3. The quality inspection system referenced by the Dongfeng Tianjin 8-ton on-board crane strictly controls the program on the visual assembly line. The turntable adopts an intelligent production line, and the intelligent rail guided vehicle is automatically docked with the welding workstation, with a docking accuracy of 0.01 degrees;

4. The Dongfeng Tianjin 8-ton on-board crane is connected to the network through intelligent welding and welding parameters. The EMS system and intelligent IoT platform are used for real-time monitoring and data collection, making the monitoring of the welding process more precise;

5. The Dongfeng Tianjin 8-ton truck mounted crane adopts a hydraulic self-locking system, which can be controlled at 360 degrees at any time during operation without producing sliding rods or movement, making the operation safer and more reliable;

6. In addition to the basic configuration of the crane, the Dongfeng Tianjin 8-ton on-board crane can be optionally equipped with torque limiting electrical system, remote control device, anti roll unloading solenoid valve, attached arm, attached hook, auxiliary winch and other devices.
