1 100P, 600P light truck: Isuzu 3-5 cubic meter vacuum suction truck
Chassis configuration: 100P, 600P light truck, equipped with 120 horsepower 4KH1CN6LB Isuzu engine, equipped with Isuzu MSB transmission/air conditioning/front axle 2-2.5 tons, rear axle 4-4.8 tons, 700R15 tires, with air conditioning, steering assistance, central locking, electric glass, multifunctional LCD instrument panel
2 KV100, KV600 light trucks: Isuzu 5-8 cubic meter vacuum suction truck
Chassis configuration: KV100, KV600 light truck, 4KH1CN6LB 120 horsepower engine or Isuzu 132 horsepower engine 4KH1CN6HB, equipped with Isuzu MSB, 5-speed transmission/air conditioning/front axle 2.5-3 tons, rear axle 4.8-5.5 tons/700-16 tires, with air conditioning, steering assistance, central locking, electric glass, multifunctional LCD instrument panel
3 700P medium truck: Isuzu 10 cubic meter vacuum suction truck
Chassis configuration: 700P medium truck, 190 horsepower 4HK1-TCG61 engine Isuzu MLD six speed transmission front axle 4 tons, rear axle 7 tons, 235/75R17.5 tires, with air conditioning, steering assistance, central locking, electric glass, multifunctional LCD instrument panel
4 FTR medium and heavy trucks: Isuzu 15 cubic meter vacuum suction truck
Chassis configuration: FTR heavy-duty truck, 4HK1-TC60 205 horsepower engine, equipped with Isuzu MLD 6-speed transmission, front axle 6.3 tons, rear axle 13 tons, tires 295/80R22.5, with air conditioning, steering assistance, central locking, electric glass, multifunctional LCD instrument panel
Isuzu chassis characteristics
- Strong power, strong vehicle carrying capacity, fast driving speed - Low fuel consumption, in the era of high oil prices, ultra-low operating costs are more prominent - Long service life, reliable and durable, ultra-low maintenance costs - High safety, equipped with unique collision energy absorption safety system - Comfortable, business class like riding experience - Low total life cost, creating more value for customers
Isuzu suction truck features:
Function: Isuzu sewage suction truck is designed and manufactured for complex urban pipe networks and surrounding working environments. Its functions cover high-pressure flushing, pipeline dredging, sewage and fecal suction, transportation of antagonists, etc. It can not only perform routine operations of suctioning solid materials such as sludge, stones, bricks, etc., but also carry out dredging and dredging of small rivers; It has faster and more efficient dredging and rescue functions, and can be used for waste suction, dredging, cleaning, reverse discharge, transportation, loading and unloading in urban sanitation, disaster relief, and special industries such as petrochemicals.
High homework efficiency: High suction rate: It only takes 3 minutes to fill the entire can in one suction; Long suction distance and high suction stroke: The horizontal suction distance can reach 50m, and the vertical suction stroke can reach over 9m. With the addition of special devices, the suction stroke is greater than 14m, resulting in high operational efficiency!
Intelligent operation: adopting hydraulic, electrical, and pneumatic control, multiple automatic protection devices, humanized and visualized design, effectively ensuring the safety of operators.
Isuzu 2-5 cubic meter sewage suction truck is a new type of multifunctional sewage suction truck developed by Chengli Special Purpose Vehicle Co., Ltd. according to the demand of the environmental sanitation market.
The car adopts an Isuzu light truck chassis, equipped with vacuum suction pump, pressure tank, hydraulic part, pipe network system, vacuum pressure gauge, oil-water separator, sight window, hand washing device, etc. It is modified and installed with engines such as full diesel and Yunnei, and its emissions meet the National V standard.
A sewage suction truck is a new type of environmental sanitation vehicle that collects, transfers, and transports sludge and sewage to avoid secondary pollution. The sewage suction truck can self suction and discharge, with fast working speed, large capacity, and convenient transportation. It is suitable for the suction, transportation, and discharge of feces, mud, crude oil, and sediment in sewers, especially for larger objects such as sewage sludge, mud, stones, bricks, etc.
Characteristics of Isuzu suction truck
The sewage suction truck has the characteristics of high suction efficiency, self suction, self discharge, and direct injection. Filling time of manure tank: ≤ 5 minutes, suction stroke: ≥ 8m. It has the characteristics of long service life, fast working speed, easy operation, and convenient transportation.
Adopting high-power vacuum suction pump and high-quality hydraulic system, the tank head is formed by one-time pressing, the tank can be opened backwards, and the double top is self dumping.
It has the characteristics of high vacuum degree, large tonnage, high efficiency, and wider application, and can be widely used for the suction, transportation, and discharge of sludge, sewage, or sediment from petrochemical wastewater tanks in urban rainwater wells, inspection wells, and various ditches.
The dirt inside the tank can be directly dumped through the back cover, and is used in various departments such as environmental sanitation, municipal, agricultural, chemical, industrial and mining enterprises, property management communities, etc. in large, medium, and small towns.
Special function description for sewage suction vehicle
The material of the suction truck tank body is high-quality carbon steel, and stainless steel can be selected. Tank metal paint.
The suction truck is equipped with an imported anti overflow device to prevent feces and sewage from being filled and poured back into the vacuum pump system.
The suction truck has a hydraulic lifting and self dumping function, which facilitates the dumping of various types of sludge. Moreover, the rear tank door can be automatically opened by hydraulic pressure, which facilitates the cleaning of sediment and solidified substances inside the tank and the maintenance of the interior of the tank.
The tank capacity specification of the sewage suction truck is 2-30 cubic meters, which can be used for watering, transporting water, and flushing roads. It can also be used for firefighting in emergency situations. (Optional sprinkler function) or multi-functional integrated vehicle; Such as dual-purpose sewage and fecal suction vehicles, high-pressure cleaning vehicles with sewage suction belts, etc.
Chengli Special Purpose Vehicle Co., Ltd. produces customized multifunctional cleaning and suction vehicles of various specifications and models, with the main brand; Dongfeng, Foton, Shacman, Sinotruk howo, FAW, Isuzu, JAC etc. For specific configurations, please feel free to consult
