| General | Approx. Dimension | 12280*2500*3900 mm |
| GVW./Kerb Wt. | 40000 / 7100 kg | |
| Fuel tanker | Axles | FUWA brand ,3x13 tons |
| Landing legs | Heavy duty landing legs 28T | |
| Suspension system | 8-piece steel plate spring suspension | |
| King pin | 90# | |
| Tires | 12R22.5, 12 pieces | |
| Total volume | 42m3 | |
| Tanker material | Aluminum alloy 5162 6mm thickness | |
| Tank top guardrail | Segmented elevated guardrail with anti-skid mesh | |
| Hose storage box | 1 box on each side (left& right) | |
| Fire protection device | 2 units 8kg fire extinguishers | |
| Anti static device | One static conductive drag belt and one static conductive terminal block | |
| Electric system | 24V lighting system ,7-pole distribution cable |
Fuel transport tank trailer is suitable for transporting gasoline, kerosene, diesel, vegetable oil, edible oil, heavy oil, coal tar and non-petroleum products such as alcohol, aldehyde, benzene, ether and other liquid substances.
Fuel tanker body structure consist of tanker bottom welded structure ,oil outlet ,tanker body , suspension , bottom beam ,manhole ,axles and outrigger ,walkway ,tool box
The trailer could optional many compartments for customer’s required convenient loading of different media oil product .Inside fuel tanker there are wave-proof plate has more fluid inflow holes than the compartment plate .
Tanker : the stee thickness of tank body is 5mm and head 6mm silo board wave proof plate for 5mm or 4mm .
Tanker material could optional aluminum alloy tanker or stainless steel or carbon steel
Fuel tanker capacity : 38000l -60,000L
Fuel tanker loading : Fill from top or bottom loading
The fuel tanker trailer has a variety of refueling or oil transportation functions according to different purposes and usage environments. Including oil absorption, oil pumping, fuel storage and various oil packaging and distribution functions.
The fuel tanker trailer has a variety of refueling or oil transportation functions according to different purposes and usage environments. Including oil absorption, oil pumping, fuel storage and various oil packaging and distribution functions.
1.European manhole 2 API drain port ,3 Landing gear 4 Traction Pin 5 Tanker container
The advantages of aluminum alloy oil tanker semi-trailer
Aluminum alloy semi-trailer oil tankers have lighter weight and can achieve more effective load capacity. Save fuel consumption.
The material of aluminum alloy semi-trailer has stronger corrosion resistance
Lower maintenance costs, no need for painting, clean and easy to clean appearance.
Aluminum alloy semi-trailer oil tanker highlights: The tank body material is made of 6mm thick 5083 aluminum alloy automatically welded, with a tank volume of 38-60 cubic meters, two European standard tank ports, one subsea valve, single compartment with pump, and can also be divided into compartments. Folding guardrail. The weld seam undergoes X-ray inspection and a tank inspection report is issued. 13 tons with three axles, optional Fuhua Bridge or BPW Bridge, 14+16+8 "I" - shaped welded beam, 90 # traction pin, 10 spring steel plates, 28 ton support legs, 16 ton brake system, with ABS.
