| Vehiecle General | Overall dimension | 4750*1620*1960 mm |
| Gross /Kerb weight | 3620/2290 kgs | |
| Chassis | Chassis brand | Foton |
| Cabin | Double cabin , left hand drive or right hand drive | |
| Engine model/power | Quanchai engine 68hp | |
| Engine emission standard | Euro III or Euro IV or Euro V or Euro VI | |
| Engine displacement | 1.8 L | |
| Transmission | 5 forwards 1 reverse | |
| Front & Rear axles | front axle 1.5tons rear axle 2.5 tons | |
| Wheelbase | 2300 2800 mm | |
| Brake system | Oil brake | |
| Tire | 6.00-13 6 tires with 1 spare tire | |
| Max speed | 95 km/h | |
| Fire Tanker | Water tanker capacity | 2000 L-3000 L |
| Tanker material | high quality carbon steel /stainless steel | |
| Fire pump | CB 10/20 flow rate 20L/S | |
| Fire cannon | PS 20 flow rate 20 L/S | |
| Control system | Cabin control & pump room control |
We are supply all brands of special truck , beiben, Faw , Foton , SHACMAN , Sinotruck howo , Jac , Jmc , Isuzu ,Dongfeng all available .
2.the drive type could be 4x2 , 4x4 , 6x2 , 6x4 , 6x6 , 8x4
3.We can provide LHD (left hand drive) or RHD (right hand drive) vehicles .
4.Widely used in chemical enterprise, oil depot, storehouse, shop and terminal market.It also can be used as main fire truck for professional fire brigade of large and medium city.
Water tank fire truck series
Water tank fire truck is one of the most used and widely used fire trucks. Because of the wide source of water, convenient absorption, and timely replenishment, it is economical, applicable, and has excellent fire-fighting effect. In addition to the fire pump and equipment, the car is also equipped with large-capacity water storage tanks, water guns, water cannons, etc. Water and firefighters can be transported to the fire site for independent fire fighting. It can also absorb water directly from the water source for fire fighting, or supply water to other fire trucks and fire sprinkler equipment. It can also be used for water supply and water delivery in water-deficient areas. It is suitable for fighting general fires. It is a standing fire vehicle for public security fire brigade and full-time fire brigade of enterprises and institutions.
Foam fire truck series
Foam fire truck, foam is an anti-soluble aqueous film-forming foam fire extinguishing agent. , strong anti-re-ignition performance. It is mainly equipped with fire pumps, water tanks, foam mixing systems, foam guns, guns and other fire fighting equipment, which can independently put out fires. It is especially suitable for fighting oil and other oil fires, and can also supply water and foam mixture to the fire site. It is a necessary equipment for petrochemical enterprises, oil terminals, airports and urban professional fire protection.
Dry powder fire truck series
It is mainly equipped with dry powder fire extinguishing agent tank, dry powder spray device, fire pump and fire fighting equipment, etc., and mainly uses dry powder to extinguish combustible and flammable liquids. Combustible gas fires, live equipment fires, and general material fires can also be put out. For large-scale chemical plant pipeline fires, the fire fighting effect is particularly significant. It is a standing fire truck for petrochemical enterprises.
